Installation process and precautions of synthetic resin tile

TIME：2023-02-07

Resin tiles are mainly used in the roofing fields such as flat to sloping, mobile houses, villas, antique buildings, garden pavilions, workshops, snack cars, etc. What are the installation principles and specific processes of resin tile? Anhui Huasu Yicai Building Materials Co., Ltd. answers for you!

Purlin can be square tube (60 × forty × 3 mm) or section steel (100 × fifty × twenty × 3mm) or anticorrosive wood (60 × 40㎜)。

Purlin spacing is 660mm, arranged from bottom to top.

The main tile shall be installed reversely according to the local wind direction. Lap a tile wave and carry out both sides at the same time.

When installing the positive ridge tile, cut off a section of the first ridge tile before installing.

The installation overlap of the positive and oblique ridge tiles shall be sawed, and the three-way tile shall be installed after the installation of the positive and oblique ridge tiles.

Fixings are special accessories. When fixing, use an electric drill to drill holes, and the hole diameter should be 2mm larger than the hook screw rod.

It is recommended to select 6.3 mm diameter self-tapping screw.
